Specifications Model 3263LColor BlackLCD Technology Active matrix TFT LCD with LED backlightDiagonal Size 31.5" / 800.1 mmActive Display Area 27.5" x 15.47" / 698.4 mm x 392.9 mmAspect Ratio 16:9Native Resolution 1920 x 1080 @ 60Preset Video Timings 640x480 @ 60Hz; 800x600 @ 56/60Hz; 1024x768 @ 60Hz; 1280x720 @ 60Hz; 1280x800 @ 60Hz RB; 1280x960 @ 60Hz; 1280x1024 @ 60Hz; 1366x768 @ 60Hz; 1366x768 @ 60Hz RB; 1440x900 @ 60Hz; 1440x900 @ 60Hz RB; 1680x1050 @ 60Hz; 1680x1050 @ 60Hz RB; 1920x1080 @ 60HzTouch Technology TouchPro® PCAP - up to 40 touches with palm rejection and touch thru capability.Number of Colors 8bit(D), 16.7Millon colorsBrightness (typical) LCD Panel: 500 nits; TouchPro PCAP: 425 nitsResponse Time (Tr + Tf) (typical) 8 msecViewing Angle (typical) Horizontal: 89°/178°; Vertical: 89°178°Contrast Ratio (typical) 3000:1On-Screen Display (OSD) Accessible through switches on the OSD Control Remote accessory. Controls: Menu, Up, Down, Select Settings: Brightness, Contrast, Clock, Phase, H-position, V-position, Auto-Adjust, Aspect Ratio, Sharpness, Color Temperature, OSD Timeout, OSD Language, Recall Defaults, Video Source, Touch, RTC, MDC, Touch Through Languages: English, French, Italian, German, Spanish, Simplified Chinese, Traditional Chinese, Japanese Lockouts: OSD, Power RTC Settings: The clock/time and the monitor ON/OFF schedule can be changed within this menu. Daylight Saving time is adjusted for automatically and will change the current time by one hour to accommodate daylight savings time. See user manual for full details.I/O Ports HDMI 1.4 x2; USB 2.0 Type B (for Touch); RJ45 (for optional OSD remote); VGA Video 2x HDCP-capable HDMI on Type A connector Female DE-15 VGA connector Input Video Horizontal Sync frequency range: 31.5 – 80 KHz Input Video Vertical Sync (frame rate) frequency range: 47 – 63 KHzMaximum Operating Time 24 hours/dayPower Input connector (power): IEC 60320-C14; Input signal specifications (power): 100-240VAC 50/60Hz Power Consumption (Typical - monitor + AC/DC adapter): ON: 51 W; SLEEP: 0.61 W; OFF: 0.20 WMounting Options VESA 400mm x 200mmOther Features Ambient Light Sensor - changes luminance to match ambient light, Auto WakeWeight Unpackaged: 24.17 lbs / 10.99 Kg; Packaged: 37.47 lbs / 17.03 KgDimensions 29.42" x 17.82" x 2.16" / 747.3 mm x 452.7 mm x 55 mmShipping Dimensions 39.4" x 12.05" x 26.79" / 1000 mm x 306 mm x 680 mmTemperature Portrait/Landscape Mode: Operating: 0° C to 40° C / 32° F to 104° F; Storage: -20° C to 60° C / -4° F to 140° F Tabletop Mode: Operating: 0° C to 35° C / 32° F to 95° F; Storage: -20° C to 60° C / -4° F to 140° FHumidity (non-condensing) Operating: 20%-80%; Storage: 10%-90% (38.7° C max wet bulb temperature)Regulatory Approvals & Declarations Argentina S-Mark; Australia RCM; Canada cUL, IC; China CCC; Europe CE; Japan VCCI; Korea KCC e-standby; Mexico CoC; Russia EAC; Taiwan BSMI; United States UL, FCC; International CB; Mexico NOM; RoHS, China RoHS, WEEE; Energy Star 8.0 compliant; CB (International safety) (IEC/EN60950- 1+IEC/EN62368-1); UL 60950 ball-drop compliant; IK07 impact compliantWarranty 3 year standard (AUR included in European regions)Extended Warranty 4 year + AUR - Elo P/N: E740135; 5 year + AUR - Elo P/N: E740330MTBF 50,000 hours demonstratedWhat’s in the Box Quick Install Guide; HDMI 1.4 cable (Type A plug to Type A plug); VGA cable (DB-15 male to DB-15 male); USB cable (Type A plug to Type B plug); RJ45 Wired OSD remote; Power cable, IEC 60320-C13 to NA plug; Power cable, IEC 60320-C13 to EU/KR plug; Power cable, IEC 60320-C13 to UK plug; Energy label according to EU Regulation 2019/2013; 8 sets Flushmount Brackets 48 pcs Screws Elo Touch
